pic pic Bally BASIC 300-Baud Audio Interface pic
pic

     Pictures of the 300 Baud Bally BASIC Interface for the Astrocade. Click any picture for a larger view.

300 Baud Interface (Front) 300 Baud Interface (Back) 300 Baud Interface
300 Baud Audio Interface, PCB - Front 300 Baud Audio Interface, PCB - Back 300 Baud Bally BASIC Interface for the Astrocade. (PCB - Front and Back)
300 BAUD Adapter (View 1) 300 BAUD Adapter (View 2) 300 BAUD Adapter (View 3) 300 BAUD Adapter (Front) 300 BAUD Adapter (Back) 300 Baud Bally BASIC Interface Adapter for the Astrocade.
300 Baud Interface Thumbnail 300 Baud Bally BASIC Interface for the Astrocade
300 Baud Interface Thumbnail 300 Baud Bally BASIC Interface for the Astrocade. This picture is from the BPA Owner's Manual, page 19. Note that it looks different from the final product.
Bally 300-Baud Tape Interface "Bally BASIC" 300-Baud Tape Interface
